8.2 Description of the possible configurations
CAUTION!
The set value should remain at the value 1 and should be changed in exceptional cases.
CAUTION!
No further density corrections may be configured. No other values may be entered under P5 RS.
CAUTION!
No further density corrections may be configured. No other values may be entered under P6 RE.
CAUTION!
No further density corrections may be configured. No other values may be entered under P2 mA.
P0 Den Density correction
Configuration of the density of the medium to be measured
This may, for example, be relevant for the level measurement in order to display the correct
filling height from the measured pressure.
P1 Uni Pressure measuring unit
The pressure value unit can be configured here. The pressure value unit is shown on the
display and can be taken from the HART® protocol.
P2 mA Measuring range lower range value
Configuration of the device (measuring range) with pressure specification
If the tank is empty, the start point (zero point) of the pressure/level measurement can be
set here. The advantage of this procedure: The device is immediately configured for the ap-
plication (e.g. tank).
P3 mA Measuring range upper range value
Configuration of the device (measuring range) with pressure specification
If the tank is full, the end point (full) of the pressure/level measurement can be set here. The
advantage of this procedure: The device is immediately configured for the application (e.g.
tank).
P4 Sec Attenuation
Time constant defined in seconds
Depending on the default setting, it is ensured that the measured value responds with a de-
lay to short, fast pressure changes.
P5 RS Measuring range lower range value
Configuration of the device (measuring range) without pressure specification
Any values can be entered here as the lower range value. It is important when, for example,
a differential pressure measurement with a diaphragm seal is attached to an application
(e.g. filling level) and no configuration with a pressure specification can be performed.
There is a calculation example available under chapter 8.4 "Level measurement configura-
tion without a pressure specification with or without a diaphragm seal", Page 61.
P6 RE Measuring range upper range value
