Measurement The water temperature is measured.
- The measured temperature rises above the upper limit (90.0 °C).
- The measured temperature drops below the lower limit (50.0 °C).
- The measured temperature lies within the limits (50.0 to 90.0 °C).
v Chapter 5 “Data logger”
high limit
low limit
evaluated
range
measured temp. (95.0 °C)
symbol displayed
TAG name screen
high limit
low limit
evaluated
range
measured temp.
(45.0 °C)
symbol displayed
TAG name screen
high limit
low limit
evaluated
range
TAG name screen
symbol displayed
measured temp. (80.0 °C)
