Jungheinrich AMX Inox User Manual

0708.GB
B 4
4 Standard Version Specifications
Z
Technical data specified in accordance with VDI 2198.
Technical modifications and additions reserved.
4.1 Performance data for standard trucks
4.2 Dimensions
Description AMX 10 Inox/
Inox Pro/
Inox Pro Ex
AMX-E 10
Inox/Inox Pro
Drive unit: Manual Electric (lift)
Q Rated capacity 1000 1000 Kg
c Load centre of gravity 600 600 mm
x Load distance 925 925 mm
Lowering speed
with / without load 0.15/0.093 0.08/0.05 m/s
Lift motor, output where s
3
10% - 0,9 kW
Battery voltage, rated capacity k
5
- 12/60 V / Ah
Battery weight - 20 Kg
Description AMX 10 Inox/
Inox Pro/
Inox Pro Ex
AMX-E 10
Inox/Inox Pro
h
3
Lift 800 800 mm
h
13
Lowered height 85 85 mm
h
14
Tiller in neutral position. 1195 1195 mm
y Wheelbase 1140 1140 mm
s/e/l Fork dimensions
50/163/1140 50/163/1140
mm
l
1
Overall length 1480 1580 mm
l
2
Length incl. fork shank 340 440 mm
b
1
/ b
2
Overall width 540/680 540/680 mm
b
5
Outer load fork distance 540 540 mm
b
1
Load bearing part track width 540 540 mm
m
2
Ground clearance 28 28 mm
A
st
Aisle width 800x1200 longit. 1830 1890 mm
Wa Turning radius 1300 1396 mm
0708.GB
B 4
4 Standard Version Specifications
Z
Technical data specified in accordance with VDI 2198.
Technical modifications and additions reserved.
4.1 Performance data for standard trucks
4.2 Dimensions
Description AMX 10 Inox/
Inox Pro/
Inox Pro Ex
AMX-E 10
Inox/Inox Pro
Drive unit: Manual Electric (lift)
Q Rated capacity 1000 1000 Kg
c Load centre of gravity 600 600 mm
x Load distance 925 925 mm
Lowering speed
with / without load 0.15/0.093 0.08/0.05 m/s
Lift motor, output where s
3
10% - 0,9 kW
Battery voltage, rated capacity k
5
- 12/60 V / Ah
Battery weight - 20 Kg
Description AMX 10 Inox/
Inox Pro/
Inox Pro Ex
AMX-E 10
Inox/Inox Pro
h
3
Lift 800 800 mm
h
13
Lowered height 85 85 mm
h
14
Tiller in neutral position. 1195 1195 mm
y Wheelbase 1140 1140 mm
s/e/l Fork dimensions
50/163/1140 50/163/1140
mm
l
1
Overall length 1480 1580 mm
l
2
Length incl. fork shank 340 440 mm
b
1
/ b
2
Overall width 540/680 540/680 mm
b
5
Outer load fork distance 540 540 mm
b
1
Load bearing part track width 540 540 mm
m
2
Ground clearance 28 28 mm
A
st
Aisle width 800x1200 longit. 1830 1890 mm
Wa Turning radius 1300 1396 mm
