2 Description of Operating and Display Elements

Item. Operating or

Display Element

Function

1 key switch t Switches current on and off.

By removing the switch the truck cannot be

switched on by unauthorised persons.

Keypad

(CANCODE)

o Sets the code and switches on the truck

2 Main Switch (Emergency

disconnect)

t The supply current is interrupted, all

electrical functions are switched off and the

truck brakes are applied automatically.

3 Multi-Pilot t Function operation:

– Travel forward / reverse

– Lift/lower load pickup

– Extend / retract mast holder

– Tilt hoist fram forward or backward, fork

tilt

– Sideshift left / right

– Horn button

– Auxiliary hydraulics (HF5) (o)

4 Steering switch t Change steering range from 180° or 360°.

5 Sideshift centring switch o Sideshift positioned in centre

6 Forks horizontal switch o Forks set to horizontal position (fork tilter

only)

7 Lock for arm rest t Longitudinal displacement of arm rest

8 Driver’s seat lock t The driver’s seat can be adjusted

horizontally

9 Driver’s seat weight

adjustment

t Adjusting driver’s weight for optimal seat

cushioning

10 Backrest adjustment t The driver’s seat backrest can be adjusted

11 Accelerator t The traction speed is infinitely variable

12 Brake Pedal t Brake applied to truck

13 Dead man pedal t – Not Activated: Travel inhibited, truck

brought to rest.

– Activated : Travel released

t = Series Equipment o = Auxliary Equipment
