Figure 37: DC Power Supply Faceplate for an EX4650
5—1— ESD grounding pointShunt negative input terminals (+RTN)
6—2— Fault LEDShunt positive input terminals (-48V)
7—3— Output LEDTerminal block
8—4— Input LEDEjector lever
CAUTION: The V+ terminals are shunted internally together, as are the V- terminals.
The same polarity terminal can be wired together from the same source to provide
an additional current path in a higher power chassis. Do not connect the terminals to
different sources.
93
