Juniper QFX5120-48Y-AFO2 Hardware Guide

Table 32: Console Port Connector Pinout Information
DescriptionSignalPin
No ConnectionNC1
No ConnectionNC2
Transmit dataTxD Output3
Signal groundSignal Ground4
Signal groundSignal Ground5
Receive dataRxD Input6
No ConnectionNC7
No ConnectionNC8
RJ-45 Management Port Connector Pinout Information
Table 33 on page 82 provides the pinout information for the RJ-45 connector for the management port
on Juniper Networks devices.
Table 33: RJ-45 Management Port Connector Pinout Information
DescriptionSignalPin
Transmit/receive data pair 1TRP1+1
Transmit/receive data pair 1TRP1—2
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 3TRP3+4
Transmit/receive data pair 3TRP3—5
Transmit/receive data pair 2TRP2—6
Transmit/receive data pair 4TRP4+7
82
