8-Port Gigabit Ethernet SFP XPIM Basic Configuration
The 8-Port Gigabit Ethernet small form-factor pluggable Gigabit-Backplane Physical
Interface Module (SFP XPIM) provides connectivity to a single Gigabit Ethernet device
or to a network. After you install the XPIM in the services gateway, you configure a network
interface on the XPIM.
NOTE: The SRX550 High Memory Services Gateway does not support
hot-swappable functionality for GPIMs.
To configure a network interface on the 8-Port Gigabit Ethernet SFP XPIM :
1. Verify that the 8-Port Gigabit Ethernet SFP XPIM is installed in the services gateway:
user@host >show chassis hardware
Hardware inventory:
Item Version Part number Serial number Description
Chassis DA3515AK0016 SRX550M
Midplane REV 03 750-063950 ACMW7426
Routing Engine REV 03 711-062269 ACMT8374 RE-SRX550M
FPC 0 FPC
PIC 0 6x GE, 4x GE SFP Base
PIC
Xcvr 6 REV 02 740-011613 PLN4Q4R SFP-SX
Xcvr 7 REV 02 740-011613 PLH5R83 SFP-SX
Xcvr 8 REV 02 740-011613 PPF68ZA SFP-SX
Xcvr 9 REV 02 740-011613 AM1301SZEZL SFP-SX
FPC 1 REV 00 750-064611 ACMX2090 FPC
PIC 0 1x T1E1 mPIM (RoHS)
FPC 2 REV 00 750-064613 ACMW2386 FPC
PIC 0 1x Serial mPIM (RoHS)
FPC 3 REV 00 750-064614 ACMZ1330 FPC
PIC 0 16x GE POE gPIM (RoHS)
FPC 6 REV 02 750-064615 ACMS8119 FPC
PIC 0 8x SFP gPIM (RoHS)
Xcvr 0 REV 01 740-013111 92244027 SFP-T
Xcvr 1 REV 02 740-011613 PLH5KLM SFP-SX
Xcvr 2 REV 02 740-011613 PPF68YU SFP-SX
Xcvr 3 REV 02 740-011613 PN356ST SFP-SX
Xcvr 4 REV 02 740-011613 PLN54T1 SFP-SX
Xcvr 5 REV 01 740-020465 DDK2008229 SFP-1000BASE-BX10-D
Xcvr 6 REV 02 740-011613 PPF68YV SFP-SX
Xcvr 7 REV 02 740-011613 PPF68YW SFP-SX
Power Supply 0 Rev 04 740-028131 WG02251 PS 645W DC
Power Supply 1 Rev 04 740-028131 WH02925 PS 645W DC
2. Verify that the PIC on the XPIM is online:
user@host> show chassis fpc pic-status
3. Verify that the network interface that you want to configure on the XPIM is up:
Copyright © 2017, Juniper Networks, Inc.88
SRX300 Series and SRX550 High Memory Gateway Interface Modules Reference
