Juniper SRX300 Series User Manual

Table 48: V.35 DTE Cable Pinouts for the 1-Port Serial
Mini-PIM (continued)
Description
LFH-60
PairingM/34 PinLFH-60 Pin
Receive Timing (B)5X6
Transmit Timing (A)55Y56
Transmit Timing (B)56AA55
---22 to 21
---26 to 25
---18 to 17
Related
Documentation
EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 56
•
• RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 58
• X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 66
X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 49 on page 65 gives the X.21 DCE cable pinouts.
Table 49: X.21 DCE Cable Pinouts for the 1-Port Serial Mini-PIM
DescriptionLFH-60 PairingDB-15 PinLFH-60 Pin
Shield Ground-115
Transmit Data (A)221
Control (A)38337
Receive (A)59460
Indicate (A)47548
Signal Element Timing (A)51652
Signal Ground-857
Transmit Data (B)192
65Copyright © 2017, Juniper Networks, Inc.
Chapter 10: Serial Mini-Physical Interface Module Cable Specifications

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
