I2C interface for module monitor and identification
•
Maximum module power of 40 W without PoE
•
JTAG support for boundary scan test
CAUTION: If you face a problem running a Juniper Networks device that uses
a third-party optic or cable, the Juniper Networks Technical Assistance Center
(JTAC) can help you diagnose the source of the problem. Your JTAC engineer
might recommend that you check the third-party optic or cable and potentially
replace it with an equivalent Juniper Networks optic or cable that is qualified
for the device.
Related
Documentation
8-Port Gigabit Ethernet SFP XPIM Components on page 30•
• 8-Port Gigabit Ethernet SFP XPIM Hardware Specifications on page 31
• 8-Port Gigabit Ethernet SFP XPIM LEDs on page 31
• 8-Port Gigabit Ethernet SFP XPIM Supported Transceivers on page 32
• 8-Port Gigabit Ethernet SFP XPIM Network Interface Specifications on page 34
8-Port Gigabit Ethernet SFP XPIM Components
The 8-Port Gigabit Ethernet small form-factor pluggable Gigabit-Backplane Physical
Interface Module (SFP XPIM) contains the components listed in Table 21 on page 30.
Table 21: 8-Port Gigabit Ethernet SFP XPIM Components
DescriptionLocationComponent
Use the ONLINE/OFFLINE button to
gracefully shut down the XPIM. Press and
hold the button for 4 to 5 seconds, and
then release. The XPIM gracefully shuts
down and turns off the power supply units
(PSUs).
To power up the XPIM (if the Services and
Routing Engine [SRE] is off), press and
hold the ONLINE/OFFLINE button for 4 to
5 seconds.
Right side of the XPIMONLINE/OFFLINE button
Use the captive screws to hold the XPIM
in place.
One on each side of
the XPIM
Two captive screws
Related
Documentation
8-Port Gigabit Ethernet SFP XPIM Overview on page 29•
• 8-Port Gigabit Ethernet SFP XPIM Hardware Specifications on page 31
• 8-Port Gigabit Ethernet SFP XPIM LEDs on page 31
Copyright © 2017, Juniper Networks, Inc.30
SRX300 Series and SRX550 High Memory Gateway Interface Modules Reference
