Juniper SRX300 Series User Manual

CHAPTER 10
Serial Mini-Physical Interface Module
Cable Specifications
•
1-Port Serial Mini-Physical Interface Module Interface Cables on page 53
•
EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 54
•
EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 56
•
RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 57
•
RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 58
•
RS-422/449 (EIA-449) DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 59
•
RS-422/449 (EIA-449) DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 61
•
V.35 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 63
•
V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 64
•
X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 65
•
X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 66
1-Port Serial Mini-Physical Interface Module Interface Cables
Table 40 on page 53 lists the cables that you can order from Juniper Networks to connect
to a port on the synchronous 1-Port Serial Mini-Physical Interface Module (Mini-PIM).
The device to which you are connecting and the serial interface types determine which
type of cable you need.
Table 40: Juniper Networks Serial Cables
Connector
TypeLengthInterface TypeProduct Number
Female3.04 m (10 ft)EIA530 cable (DCE)JX-CBL-EIA530-DCE
53Copyright © 2017, Juniper Networks, Inc.

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
