Juniper SRX300 Series User Manual

Table 46: RS-422/449 DTE Cable Pinouts for the 1-Port Serial
Mini-PIM (continued)
Description
LFH-60
Pairing
DC-37
(DB-37) PinLFH-60 Pin
Receive Ready (A)141313
Terminal Timing (A)511752
Signal Ground-1936
Receive Common-204
Send Data (B)602259
Send Timing (B)562355
Receive Data (B)1242
Request to Send (B)482547
Receive Timing (B)5266
Clear to Send (B)372738
Data Mode (B)92910
Terminal Ready (B)333034
Receiver Ready (B)133114
Terminal Timing (B)523551
Send Common-3757
--26 to 25
--18 to 17
Related
Documentation
EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 56
•
• RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 58
• V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 64
• X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 66
Copyright © 2017, Juniper Networks, Inc.62
SRX300 Series and SRX550 High Memory Gateway Interface Modules Reference

Juniper SRX300 Series Specifications

General

Memory	4 GB
CPU	Intel Atom
Storage	8 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% noncondensing
