To configure the Mini-PIM:
1. Configure the dialer pool:
user@host# set interfaces cl-slot-number/0/0 dialer-options pool number priority
number
2. Configure the profile:
user@host# request modem wireless create-profile profile-id profile-id
access-point-name l3vpn.corp authentication-methodchap sip-user-id user@myvpn.net
sip-password password
3. Activate the SIM:
user@host# set interfaces cl-slot-number/0/0 act-sim sim-slot-number
4. Select the profile and configure the radio access type for the SIM card:
user@host# set interfaces cl-slot-number/0/0 cellular-options sim sim-slot-number
profile-id profile-id
user@host# set interfaces cl-slot-number/0/0 cellular-options sim sim-slot-number
radio-access automatic
NOTE: If a SIM card is installed in the second slot, then select the profile
and configure the radio access type for the secondary SIM card as well.
5. Configure the dialer interface:
•
Always-on mode:
user@host# set interfaces dl0 unit 0 family inet negotiate-address
user@host# set interfaces dl0 unit 0 family inet6 negotiate-address
user@host# set interfaces dl0 unit 0 dialer-options pool dialer-pool-number
user@host# set interfaces dl0 unit 0 dialer-options dial-string dial-number
user@host# set interfaces dl0 unit 0 dialer-options always-on
•
Dial-on-demand mode:
user@host# set interfaces dl0 unit 0 family inet negotiate-address
user@host# set interfaces dl0 unit 0 family inet6 negotiate-address
user@host# set interfaces dl0 unit 0 family inet filter dialer dialer-filter-name
user@host# set interfaces dl0 unit 0 dialer-options pool dialer-pool-number
user@host# set interfaces dl0 unit 0 dialer-options dial-string dial-number
•
Backup mode:
81Copyright © 2017, Juniper Networks, Inc.
Chapter 11: Configuring Mini-Physical Interface Modules
