Juniper SRX320 User Manual

CHAPTER 10
Serial Mini-Physical Interface Module
Cable Specifications
•
1-Port Serial Mini-Physical Interface Module Interface Cables on page 53
•
EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 54
•
EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 56
•
RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 57
•
RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 58
•
RS-422/449 (EIA-449) DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 59
•
RS-422/449 (EIA-449) DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 61
•
V.35 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 63
•
V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 64
•
X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 65
•
X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 66
1-Port Serial Mini-Physical Interface Module Interface Cables
Table 40 on page 53 lists the cables that you can order from Juniper Networks to connect
to a port on the synchronous 1-Port Serial Mini-Physical Interface Module (Mini-PIM).
The device to which you are connecting and the serial interface types determine which
type of cable you need.
Table 40: Juniper Networks Serial Cables
Connector
TypeLengthInterface TypeProduct Number
Female3.04 m (10 ft)EIA530 cable (DCE)JX-CBL-EIA530-DCE
53Copyright © 2017, Juniper Networks, Inc.

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
