Juniper SRX320 User Manual

CHAPTER 7
LTE Mini-Physical Interface Module
•
LTE Mini-Physical Interface Module on page 39
•
LTE Mini-Physical Interface Module LEDs on page 42
•
LTE Mini-Physical Interface Module Hardware Specifications on page 43
LTE Mini-Physical Interface Module
The LTE Mini-Physical Interface Module (Mini-PIM) provides wireless WAN support on
the SRX300 Series and SRX550 High Memory Services Gateways. The Mini-PIM contains
an integrated modem and operates over 3G and 4G networks. The Mini-PIM supports up
to two SIM cards and can be installed in any of the Mini-PIM slots on the services
gateways.
The Mini-PIM supports the following features:
•
Automatic switchover between service providers through dual SIMs
•
Storage support for multiple service provider and access point name (APN) profiles
•
LTE carrier aggregation
•
SIM lock and unlock capability
•
Always-on, dial-on-demand, and backup modes
•
Over-the-Air upgrade for modem firmware
Figure 9 on page 39 shows the front panel of the LTE Mini-PIM.
Figure 9: LTE Mini-PIM Front Panel
Table 29 on page 40 lists the components on the front panel of the Mini-PIM.
39Copyright © 2017, Juniper Networks, Inc.

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
