The 1-Port Serial Mini-Physical Interface Module (Mini-PIM) supports the following
standards:
•
TIA/EIA 530
•
V.35
•
X.21
•
RS-232
•
RS-449
Related
Documentation
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) Hardware
Specifications on page 16
•
• 1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) LEDs on page 16
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) Hardware
Specifications
Table 13 on page 16 lists the physical specifications of the 1-Port Serial Mini-Physical
Interface Module (Mini-PIM).
Table 13: 1-Port Serial Mini-PIM (SRX-MP-1SERIAL-R) Physical
Specifications
ValueDescription
0.8 in. x 3.75 in. x 5.9 in.
(2.0 cm x 9.5 cm x 14.5 cm)
Dimensions (H x W x L)
3.04 oz (86 g)Weight
60-pin Synchronous Serial (female)Connector type
Mini-PIMForm factor
Related
Documentation
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) Overview on page 15•
• 1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) LEDs on page 16
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) LEDs
The 1-Port Serial Mini-Physical Interface Module (Mini-PIM) has one LED located to the
right of the serial port. Table 14 on page 17 describes the LED states.
