Table 49: X.21 DCE Cable Pinouts for the 1-Port Serial Mini-PIM (continued)
DescriptionLFH-60 PairingDB-15 PinLFH-60 Pin
Control (B)371038
Receive (B)601159
Indicate (B)481247
Signal Element Timing (B)521351
---30 to 29
Related
Documentation
EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 56
RS-422/449 (EIA-449) DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 61
V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 64
X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 66
X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 50 on page 66 gives the X.21 DTE cable pinouts.
Table 50: X.21 DTE Cable Pinouts for the 1-Port Serial Mini-PIM
DescriptionLFH-60 PairingDB-15 PinLFH-60 Pin
Shield Ground-115
Transmit Data (A)59260
Control (A)47348
Receive (A)241
Indicate (A)38537
Signal Element Timing (A)665
Signal Ground-857
Transmit Data (B)60959
Control (B)481047
Copyright © 2017, Juniper Networks, Inc.66
