Front Panel 11
Table 2: Status LED Descriptions
Type Name Color State Description
POWER Green On steadily Indicates that the system is receiving power.
Off Indicates that the system is not receiving
power.
Red On steadily Indicates that the device is not operating
normally.
Off Indicates that the device is operating
normally.
STATUS Green On steadily Indicates that the system is starting or
performing diagnostics.
Blinking Indicates that the device is operating
normally.
Red Blinking Indicates that there was an error detected.
ISDN
devices
CH B1 Green On steadily Indicates that B-Channel 1 is active.
Off Indicates that B-Channel 1 is not active.
CH B2 Green On steadily Indicates that B-Channel 2 is active.
Off Indicates that B-Channel 2 is not active.
V.92
devices
HOOK Green On steadily Indicates that the link is active.
Off Indicates that the serial interface is not in
service.
TX/RX Green Blinking Indicates that traffic is passing through.
Off Indicates that no traffic is passing through.
WLAN
devices
802.11A Green On steadily Indicates that a wireless connection is
established but there is no link activity.
Blinking Indicates that a wireless connection is
established. The baud rate is proportional to
the link activity.
Off Indicates that there is no wireless connection
established.
B/G Green On steadily Indicates that a wireless connection is
established but there is no link activity.
Blinking Indicates that a wireless connection is
established. The baud rate is proportional to
the link activity.
Off Indicates that there is no wireless connection
established.
