Default Device Settings 27
Default Device Settings
This section describes the default settings and operation of an SSG 5 device.
Table 4 shows the default zone bindings for ports on the devices.
Table 4: Default Physical Interface to Zone Bindings
A bridge group (bgroup) is designed to allow network users to switch between wired
and wireless traffic without having to reconfigure or reboot the device. By default,
the ethernet0/2 — ethernet0/6 interfaces, labeled as ports 0/2 — 0/6 on the device,
are grouped together as the bgroup0 interface, have the IP address 192.168.1.1/24,
and are bound to the Trust security zone. You can configure up to four bgroups.
If you want to set an Ethernet or a wireless interface into a bgroup, you must first
make sure that the Ethernet or wireless interface is in the Null security zone.
Unsetting the Ethernet or wireless interface that is in a bgroup places the interface
in the Null security zone. Once assigned to the Null security zone, the Ethernet
interface can be bound to a security zone and assigned a different IP address.
Port Label Interface Zone
10/100 Ethernet ports:
0/0 ethernet0/0 Untrust
0/1 ethernet0/1 DMZ
0/2 bgroup0 (ethernet0/2) Trust
0/3 bgroup0 (ethernet0/3) Trust
0/4 bgroup0 (ethernet0/4) Trust
0/5 bgroup0 (ethernet0/5) Trust
0/6 bgroup0 (ethernet0/6) Trust
AUX serial0/0 Null
WAN p orts:
ISDN bri0/0 Untrust
V.92 serial0/0 Null
