3. WLAN Access Point Window
If you are using the device in the WORLD or ETSI regulatory domain, you must
choose a country code. Select the appropriate option, then click Next.
Figure 21: Country Code Window
4. Physical Interface Window
On the interface-to-zone bindings screen, you set the interface to which you want to
bind the Untrust security zone. Bgroup0 is prebound to the Trust security zone.
Ethernet0/1 is bound to the DMZ security zone but is optional.
Figure 22: Physical Interface Window
After binding an interface to a zone, you can configure the interface. The
configuration windows displayed after this point depend on which SSG 5 device you
are using as part of your network. To continue configuring your device with the
ICW, click Next.
