Chapter 2—System Concepts
Fusion Catalyst 4000 Getting Started Guide 5
2. System Concepts
The Fusion Catalyst 4000 is shipped in a single cardboard carton. The
carton contains the Fusion Catalyst 4000 chassis and a tray that contains
all the components that go with the system. The contents of this box and
tray are listed below.
2.1 Chassis
Jupiter recommends that two people be present when unpacking the
chassis. To unpack:
1. Open the box, remove the components tray from the carton, and
set it aside.
2. Fold the flaps back against the sides of the box; while one person
holds the carton, another person can lift the chassis (with foam
packing) out of the carton.
3. Remove the foam packing pieces and place the Fusion Catalyst
chassis on a bench or table.
