ControlsandFeatures
MainUnitFront
.
ABC
D
E
E
A
Lens
Thisisaprojectionlens.Donotlookthroughthelens
whileanimageisprojected.
B
Lenscover

Thelenscoveropens/closeswhenthepowersupply
isturnedon/off.(p.55)

For,attachthelenscoverwhentheunitis
notinuse.
C
RemoteSensor(front)
Pleaseaimtheremotecontrolatthisareawhenusing
it.
*Thereisalsoaremotesensorattherear.
D
Indicator
Referto“IndicatorDisplayontheMainUnit”(p.81).
E
Exhaustvent
Warmairisdischargedtocooldowntheinternal
temperature.
Donotblockthevents.
MainUnitBottom
F
Inlets(at3pointsontherear/bottom)
Theinletstakeinairtocooldowntheinternaltemperature.
Donotblockorpreventtheoutflowofhotair.Doingsomaycause
theunittomalfunction.
*Therearetwoinletsontherightandleftsidesattherearoftheunit.
G
Manualbuttonforlenscover

Thelenscovercanbeopenedwhenpresseddown.
Itisusedformaintenancepurposes.Youcanalsomakeuseofit
whenyouneedtoopenthelenscoverurgently.
H
Feet
Theheightandangleoftheprojectorcanbeadjustedbyturningthe
foot.(0to5mm)(p.21)
Whenthefootisremoved,itcanbeusedasthemountingholesfor
theceilingmountbracket.
FG
H
14
