ConnectingtheProjector

Donotturnonthepoweruntilconnectioniscomplete.

Theconnectionproceduresdifferaccordingtothedeviceused.Fordetails,pleaserefertotheinstructionmanual
ofthedevicetobeconnected.

Thisprojectorisusedforprojectingimages.Tooutputtheaudioofconnecteddevices,pleaseconnectaseparate
audiooutputdevice,suchasanamplifierorspeaker.

Theimagesmaynotbedisplayeddependingonthedevicesandcablestobeconnected.
UseonlyHDMIcables(soldseparately)thatareHDMIcertified.

Somecablescannotbeconnectedtothisunitduetothesizeoftheirconnectorcover.
ConnectingtotheHDMIInputTerminal(DigitalInput)
ConnectingviaHDMIcable
.
HDMI Output Terminal
BD/DVD Recorder, etc.
Laptop, etc.
HDMI Cable (Sold Separately)
This Unit
To [HDMI 1] or [HDMI 2] input
terminal

Ifnoiseoccurs,movethelaptopawayfromthisunit.

ForatransmissionbandwidthincompliancewiththeHDMIstandard,a340MHzcableisrecommended.When
usingacablewithabandwidthof75MHz,youarerecommendedtosettheresolutionoftheequipmenttransmitting
thevideoto1080iorlower.

Ifthevideoisnotdisplayed,trytoreducethelengthofthecableorlowertheresolutionofthevideotransmitting
equipment.
ConnectingviaHDMIDVIconversioncable
.

HDMI-DVI Conversion Cable (Sold Separately)
To [HDMI 1] or [HDMI 2] input
terminal
This Unit
DVI Output Terminal
Desktop PC, etc.

Ifnoiseoccurs,movethedesktopPCawayfromthisunit.

Ifthevideoisnotdisplayed,trytoreducethelengthofthecableorlowertheresolutionofthevideotransmitting
equipment.
