Item Description
Items that are shaded ( ) are common to all modes.
Settings with the R mark are default values.
CAMERA PROCESS
GAIN L For setting the gain value for each position on the GAIN switch.
GAIN M (Fixed at AGC when in FULL AUTO mode A)
GAIN H 0dB
3dB
6dB
9dB
12dB
15dB
18dB
AGC
<Factory settings>
GAIN L:0db GAIN M:9 dB GAIN H:18 dB
PHOTOMETRY AREA For setting the area for brightness correction.
R WHOLE SCREEN: Sets the entire screen as the photometry area.
SPOT : A separate screen is displayed. (A Page 38)
Specify the photometry area.
COLOR BAR For setting whether to output color bars. (Fixed at [OFF] when in FULL AUTO mode A)
R OFF : Color bars are not output.
ON : Color bars are output.
TELE MACRO For selecting whether to shorten the closeup distance at the tele (T) end of the zoom lens.
R OFF : Enables closeup shots up to about 1 m.
ON : Enables closeup shots up to about 80 cm.
FILE FORMAT For setting the video file format.
R QuickTime file format : Records in the QuickTime(MOV) format.
MP4 file format : Records in the MP4 file format.
Memo :
● The display color of the recording mode icon on the status screen changes according to the
settings in the [FILE FORMAT] menu.
When set to [QuickTime file format] : Blue
When set to [MP4 file format] : Orange
SYSTEM SELECT For setting the system of this camcorder.
R 1080-60/30 : Vertical resolution of 1080 lines, frame rate of 60/30
720-60/30 : Vertical resolution of 720 lines, frame rate of 60/30
1080-50/25 : Vertical resolution of 1080 lines, frame rate of 50/25
720-50/25 : Vertical resolution of 720 lines, frame rate of 50/25
1080-24 : Vertical resolution of 1080 lines, frame rate of 24
720-24 : Vertical resolution of 720 lines, frame rate of 24
Memo :
● When the setting of this item is altered, the camcorder will reboot (restart) automatically.
