JVC GY-HM100U - Remote Control; Dimensional Outline Drawing

75
Remote Control
Dimensional Outline Drawing
(Unit: mm)
● The specifications and appearance of this product are subject to changes for further improvement without prior notice.
Type : DC 3 V (button battery CR2025)
Battery life : Approx. 1 year (varies according to
frequency of use)
Operating distance : Approx. 5 m (16.4ft) (along front axis)
Allowable operating
temperature
: 0°C to 40°C (32°F to 104°F)
Dimensions : 42 mm (W) × 14.5 mm (H) × 91 mm (D)
(1-6/8" × 9/16" × 3-5/8")
Mass : Approx. 30 g (0.07 lbs)
(including button battery)
CH-2 INPUT
CH-1
3
4
5
2
1
2
3
0
CH-2
AUDIO INPUT
AUTO MANUAL
AUTO MANUAL
USER1
GAIN
L-
M-
H-
B-
A-
PRST-
WHT.BAL A / B
AB
FOCUS
ZOOM
ON
ND
FILTER
OFF
USER2
AF/MF FULL AUTO
AUDIO
SELECT
INPUT1
INPUT2
- LINE -
- MIC -
MIC+48V
AWB
SNAP
SHOT
TW
INPUT2
INPUT1
135 114 100
102 154 179
184
200
272
366
138
30
(hood)
(without battery)
(with battery)
