(No.YA098) 1-11
66 D12 D12 I/O Data (Program ROM)
67 D10 D10 I/O Data (Program ROM)
68 VSS33 VSS33 - GND
69 VDD33 VDD33 I 3.3V
70 D4 D4 I/O Data (Program ROM)
71 D3 D3 I/O Data (Program ROM)
72 D11 D11 I/O Data (Program ROM)
73 RSTIN RSTIN I Reset
74 POWER P3.0 O Sleep state release for chassis CPU [Relese : L]
75 ID_TV_POWER(IDTV) P3.1 O Not used
76 REMOCON P3.2 I Remote control
77 PIX CLOCK P3.3 I Clock for OSD
78 OSDR0 P3.4 O Red for OSD
79 OSDR1 P3.5 O Red for OSD
80 OSDR2 P3.6 O Red for OSD
81 OSDR3 P3.7 O Red for OSD
82 MRST(Sirial) P3.8 I/O Communication for chassis CPU (Serial data)
83 MTSR(Sirial) P3.9 I/O Communication for chassis CPU (Serial data)
84 VSS33 VSS33 - GND
85 VDD33 VDD33 I 3.3V
86 VSS25 VSS25 - GND
87 VDD25 VDD25 I 2.5V
88 MICON TX TXD0 I/O Communication for adjustment (Serial data)
89 MICON RX RXD0 I/O Communication for adjustment (Serial data)
90 OSDR4 P3.12 O Red for OSD
91 CLK(Sirial) P3.13 O Communication for chassis CPU (Clock)
92 OSDG0 P3.15 O Green for OSD
93 OSDG1 P5.14 O Green for OSD
94 OSDG2 P5.15 O Green for OSD
95 OSDG3 TRIG_IN O Green for OSD
96 OSDG4 TRIG_OUT O Green for OSD
97 OSDG5 P6.2 O Green for OSD
98 SCL3A P6.3 I/O I
2
C bus clock (for main memory)
99 SDA3A P6.4 I/O I
2
C bus Data (for main memory)
100 TEXT / OTHER P6.5 O Teletext signal select [Analog RGB : H Digital RGB : L]
101 IRQ(IDTV) P6.6 O Not used
102 V_PULSE VSYNC I Vertical sync
103 H_PULSE HSYNC I Horizontal sync
104 (COR/RSTOUT) COR/RSTOUT O Not used
105 Ys BLANK/CORBLA O Ys for OSD / Teletext
106 VDD33 VDD33 I 3.3V
107 VSS33 VSS33 - GND
108 XTAL1 XTAL1 I 6MHz for system clock
109 XTAL2 XTAL2 O 6MHz for system clock
110 VSSA VSSA - GND
111 VDDA VDDA I 2.5V
112 R R O R for OSD / Teletext
113 G G O G for OSD / Teletext
114 B B O B for OSD / Teletext
115 VSSA VSSA - GND
116 VDDA VDDA I 2.5V
117 CVBS CVBS2 I Video for Teletext
118 VSSA VSSA - GND
119 VDDA VDDA I 2.5V
120 GND CVBS1B I GND
121 CVBS CVBS1A I Video for Teletext
122 VSSA VSSA - GND
123 VDDA VDDA I 2.5V
124 F_KEY_1 P5.0 I Key scan data 1 [ON : H]
125 F_KEY_2 P5.1 I Key scan data 2 [ON : H]
126 POWER_KEY P5.2 I Main power ON / OFF control [ON : L]
127 NC P5.3 I Not used
128 (TMODE) TMODE I Test purpose
Pin No. Terminal name Port name I/O Remark
