JVC PD-35B50BJ - Page 16

1-12 (No.YA098)
1 NC P60 O Not used
2 P_MU P61 O Viveo mute [Mute : H]
3 FUNC_LED P62 O Not used
4 A_MU P63 O Audio out mute [Mute : H]
5 M_MU P50 O Monitor out mute [Mute : H]
6 PC_SW P51 O PC input switch [ON : H]
7 DIMMER_LED P52 O Power LED brightness control [Low brightness : L]
8 NC P53 O Not used
9 NC P54 O Not used
10 NC P55 O Not used
11 POW_LED P56 O Power LED control [ON : H]
12 NC P57 O Not used
13 SBT2 SBT2 I Communication for main CPU (Clock)
14 SBI2 SBI2 I/O Communication for main CPU (Serial data)
15 SBO2 SBO2 I/O Communication for main CPU (Serial data)
16 REQ P23 O Communication for main CPU (Request)
17 3.3V VDD I 3.3V
18 NC PB0 O Not used
19 GND VSS - GND
20 3.3V XI I 3.3V
21 NC XO O Not used
22 3.3V VDD I 3.3V
23 OSCI OSCI I 16MHz for system clock
24 OSCO OSCO O 16MHz for system clock
25 3.3V (MODE) I 3.3v
26 NC P24 O Not used
27 A92_RST P25 O 3D YC separator reset [Reset : L]
28 NC P26 O Not used
29 LIP_RST P27 O Lip sync reset [Reset : H]
30 NC KI0 O Not used
31 NC KI1 I Not used
32 NC KI2 O Not used
33 MDR_CON P33 I Not used
34 3.3V AVDD I 3.3V
35 NC P34 O Not used
36 DsyncSW2 P35 O Not used
37 NC P36 O Not used
38 NC P37 O Not used
39 HOTPLUG P40 I Not used
40 MECA_SW P41 I Power switch input [ON : L]
41 MAIN_POW P42 O Main power control [ON : L]
42 MSP_RESET P43 O Multi sound processor reset [Reset : H]
43 0V Vref- I GND
44 NC AN4 I Not used
45 AFT1 AN5 I Tuner AFT detection [Detection : H]
46 NC AN6 I Not used
47 NC AN7 I Not used
48 NC P80 O Not used
49 NC P81 O Not used
50 NC TM0IO I Not used
51 NC SBI3 O Not used
52 NC SBO3 I Not used
53 NC P85 O Not used
54 3.3V Vref+ I 3.3V
55 PDP_TX SBI4 O PDP communication for sub CPU
56 PDP_RX SBO4 I PDP communication for sub CPU
57 SDA0 P90 I/O I
2
C bus data (for chassis memory)
58 SCL0 P91 I/O I
2
C bus clock (for chassis memory)
59 SDA_DVI P92 I/O Not used
60 SCL_DVI P92 I/O Not used
61 GND AVSS - GND
62 NC AN0 I Not used
63 AGC AN1 I AGC voltage level detection [Detection : H]
64 YS1 AN2 I YS1 detection [Detection : H]
65 YS2 AN3 I YS2 detection [Detection : H]
Pin No. Terminal name Port name I/O Remark
2.3.3 CHASSIS CPU [IC7001] PIN FUNCTION
