(No.YA098) 1-13
66 3.3V VDD I 3.3V
67 NC P70 O Not used
68 NC P71 O Not used
69 NC P72 O Not used
70 NC P73 O Not used
71 NC SBI1 O Not used
72 NC SBO1 O Not used
73 SBD5 * I/O For flash writing
74 SBT5 * I For flash writing
75 3.3V NMI I 3.3V
76 NC IRQ0 I Not used
77 REMOCON IRQ1 I Remote control
78 V_SYNC IRQ2 I Vertical sync
79 WAKEUP_SHM IRQ3 I Sleep state release for chassis CPU [Relese : L]
80 POWERGOOD IRQ4 I Power error detection [Detection : H]
81 REC_LED PA5 O Stand-by power LED control [Stand-by :H]
82 RST RST I Chassis CPU reset [Reset : L]
83 3.3V VDD I 3.3V
84 SCL3A P00 I/O I
2
C bus clock (for 3D separator, colour management / OSD
composition / RGB A-D convert, U / V frontend, sound delay)
85 SDA3A P01 I/O I
2
C bus data (for 3D separator, colour management / OSD
composition / RGB A-D convert, U / V frontend, sound delay)
86 SCL3B P02 I/O I
2
C bus clock (for multi sound process, video / audio select,
colour demod. / sync sep. / RGB SW, 3 line comb filter,
component video / audio select, sync sep. / SW / detect)
87 SDA3B P03 I/O I
2
C bus data (for multi sound process, video / audio select,
colour demod. / sync sep. / RGB SW, component video / audio
select, sync sep. / SW / detect)
88 NC P04 O Not used
89 NC P05 O Not used
90 NC P06 O Not used
91 DVI_RST P07 O Not used
92 GND VSS - GND
93 SCL5055 P10 I/O I
2
C bus clock (for DIST)
94 NC P11 O Not used
95 SDA5055 P12 I/O I
2
C bus data (for DIST)
96 NC P13 O Not used
97 NC P14 O Not used
98 15K/OTH P15 O Y signal select for 3D YC separator [525i : H other : L]
99 DsyncSW1 P16 O Not used
100 JCC5057_BUSY P17 I Busy for Colour management / OSD composition [Busy : H]
Pin No. Terminal name Port name I/O Remark
