10.6 Temperature control, cleaning
and hydraulic oil
Replace the filter element of the return filter
CAUTION
Avoid skin contact with oil. Use protective gloves.
IMPORTANT
Be careful not to discharge oil into the environment. Use an appro‐
priate container, and deliver the oil and the used filter to a hazard‐
ous waste collection point.
Take care to ensure absolute cleanliness. Impurities in oil cause
damage to the system.
1 Remove the cover (B).
2 Replace the filter element (A).
3 Close the cover (B).
6 10 Common hydraulics – 10.6 Temperature control, cleaning and hydraulic oil
TL2 Maintenance Manual
591 003 Default
