Kalmar TL2 - Steering

Number Maintenance item Lubrication Note Reference
3 Axles
1 Lubricating the universal shaft joints (2 pcs.)
2 Lubricating the front axle kingpins (4 pcs.)
3 Lubricating the driveline slip yoke
4 Brakes
4 Lubricating the brake lever (4 pcs.)
5 Lubricating the S-cam bearings (4 pcs.)
6 Lubricating the brake shoe anchor pins (4 pcs.) Lubrication only once
a year.
5 Steering
7 Lubricating the tie rod joints (2 pcs.)
8 Lubricating the steering cylinder ends (4 pcs.)
6 Suspension
9 Lubricating the rear axle rocker bearing (2 pcs.)
7 Load handling
10 Lubricating the lifting frame bearing (2 pcs.)
11 Fifth wheel: grease nipples, jaws, slide The number of the
grease nipples varies
depending on the
customer.
12 Lubricating the fifth wheel joints (2 pcs.) Holland FW 35
13 Lubricating the lifting cylinder ends (4 pcs.)
9 Frame, body, cab, and accessories
14 Lubricating the cab tilt latch
15 Lubricating the cab door locks (2 pcs.)
16 Lubricating the cab door hinges
