Troubleshooting cables
Troubleshoot cables according to the following
instructions.
CAUTION
Ensure that the main switch is turned to the upright position (power
from the batteries to the electric devices is off) before starting to
troubleshoot the cables.
1.
Refer to the circuit diagram for the item you are troubleshoot‐
ing, check the connections and any joints of the suspected
cable.
2.
Check the cable as follows:
a)
Disconnect the connector from both the control unit and
component.
b)
Connect the other end of the cable to a point on the frame
structure where the cable touches the metal surface with‐
out a film of paint or coating.
c)
Use a multimeter to measure the cable resistance
between the cable and the machine frame.
d)
The cable is intact if the multimeter shows constant resist‐
ance.
0 Complete machine – Troubleshooting cables 5
