Pneumatic system
Operating
principle
A compressor coupled to the engine generates
the required volume flow for the pneumatic
system.
The pressure control valve at the compressor
directs the compressor output to the by-pass
line when the system pressure exceeds 8.0 bar.
Compressor
output
Approximately 500 litres per minute (Depends
on engine type and RPM).
Compressed
air tank volume
3 tanks: 89 litres.
F Technical data – Specifications and dimensional drawing 7
TL2 Maintenance Manual
591 003 Default
