Kampmann KaControl - Fan and Sensor Parameters; Minimum Fan Speed; Locking Fan Stages; Sensor Calibration

36
KaControl for Door Air CurtainsINSTALLATION AND OPERATING INSTRUCTIONS
INSTALLATION AND OPERATING INSTRUCTIONS
1.96 Door air curtains
Fan stage Value
Automatic fan mode 1
Stage 0 (OFF) 2
Stage 1 4
Stage 2 8
Stage 3 16
Stage 4 32
Stage 5 64
Example:
Locking fan stages 4,5
Fan stage Value
Automatic fan mode 11
Stage 0 (OFF) 22
Stage 1 4
Stage 2 8
Stage 3 16
Stage 4 32
Stage 5 64
Setting
Parameter P42 3
(default)
Function Standard Min Max Unit
P42 Parameter to lock the fan stages 30127
Fan stage 0 is locked by default!
Each fan stage is allocated a defined value.
The values of the locked fan stages have to be added
together and assigned to Parameter P42.
11.3.3.4 Locking Fan Stages
Parameter P42
Parameter P42 is used to lock individual fan stages (0,1,2,3,4,5,AUTO).
Locked fan stages cannot be selected manually using the KaController
11.3.4 Sensor Calibration
Parameters P58, P61, P62
Parameters P58, P61 and P62 can be used to calibrate the sensor. The temperature sensors should be
calibrated during initial commissioning and at every service.
Function Standard Min Max Unit
P58 Offset analog input Al1 0 -99 127 °C/10
(external room temperature sensor)
P61 Offset sensor in the KaController 0 -99 127 °C/10
P62 Offset analog input AI2 (clip-on sensor) 0 -99 127 °C/10
Function Standard Min Max Unit
P51 Minimum fan speed 00100 %
11.3.3.3 Minimum Fan Speed
Parameter P51
The minimum fan speed is set and limited by parameter P51.
