KaControl for Door Air Curtains
INSTALLATION AND OPERATING INSTRUCTIONS
37
Door air curtains 1.96
The temperature setpoint is shown as standard in the display. It is necessary to display the
measured room temperature to calibrate the sensor.
Set Parameter P37 = 2 to display the room temperature
(Display in room temperature display, see Section 11.3.1)
11.3.5 Function of Multifunctional Inputs AI1, AI2 and AI3
The function of the multifunctional inputs AI1, AI2 and AI3 can be configured using parameter
settings.
11.3.5.1 Function of AI1
Parameter P15
Parameter PI5 is used to set the function of the multifunctional input AI1.
The multifunctional input AI1 can only be set using Parameter P15 if DIP switch no. 6 is set to ON!
The setting of DIP switches is described in section 10.
Function Standard Min Max Unit
P58 Offset analog input Al1 0 -99 127 °C/10
(external room temperature sensor)
P61 Offset sensor in the KaController 0 -99 127 °C/10
P62 Offset analog input AI2 (clip-on sensor) 0 -99 127 °C/10
Function Standard Min Max Unit
P15 Function AI1 0 0 19
0 = Function of Al1 not used (input disabled)
1 = NTC Fresh air sensor
2 = NTC Cold / hot water sensor (clip-on sensor)
3 = NTC Cold water sensor (clip-on sensor)
4 = NTC Hot water sensor
5 = NTC External room temperature sensor / inlet air sensor
6 = 0..100 kOhm Fan actuation
7 = 0..100 kOhm Temperature setpoint
8 = 0..10 V BMS-Heating/cooling control
9 = 0..10 V BMS-Heating control
10 = Eco/Day mode . . . . . . . . . . . . . . . . . . .(contact open --> Day)
11 = No function . . . . . . . . . . . . . . . . . . . . .(contact open without function)
12 = Condensation alarm . . . . . . . . . . . . . .(Contact open --> no condensation)
13 = General alarm . . . . . . . . . . . . . . . . . . .(Contact open --> no alarm)
14 = External frost protection monitor . . .(Contact open --> no frost)
15 = Eco/Day mode . . . . . . . . . . . . . . . . . . .(contact closed --> Day)
16 = No function . . . . . . . . . . . . . . . . . . . . .(contact closed, no function)
17 = Condensation alarm . . . . . . . . . . . . . .(Contact closed --> no condensation)
18 = General alarm . . . . . . . . . . . . . . . . . . .(Contact closed --> no alarm)
19 = External frost protection monitor . . .(Contact closed --> no frost)
