KaControl for Door Air CurtainsINSTALLATION AND OPERATING INSTRUCTIONS

INSTALLATION AND OPERATING INSTRUCTIONS

1.96

Door air curtains

Function Standard Min Max Unit Comment

t001 Serial address 10207 –

t002 Baud rate 202–

0 = Baud rate 4800

1 = Baud rate 9600

2 = Baud rate 19200

t003 Background lighting function 002–

0 = Slow fade in, fast fade out

1 = Slow fade in, slow fade out

2 = Fast fade in, fast fade out

t004 Strong background lighting 405–

t005 Sensor calibration of KaController sensor 0 -60 60 °C

t006 LCD display contrast 15 0 15

t007 BEEP setting 001

0 = BEEP ON

1 = BEEP OFF

t008 Password for KaController Parameter menu 11 0 999 –

t009 Minimum settable setpoint temperature 8020 °C

t010 Maximum settable setpoint temperature 35 10 40 °C

t011 Setpoint setting interval 002–

0 = Automatic setting based on PCB

(parameterisable, freely programmable)

1 = Interval of 1℃ (parameterisable PCBs)

2 = Interval of 0.5 ℃ (freely programmable PCBs)

t012 Date/Time setting: Year 9099 –

t013 Date/Time setting: Month 1112 –

t014 Date/Time setting: Day in the month 1131 –

t015 Date/Time setting: Weekday 117–

t016 Date/Time setting: Hour 0023 –

t017 Date/Time setting: Minute 0059 –

14.3. KaController Parameter List

(Access code: 11)
