12. Control PCB Parameter List
Function Settings Min Max Unit Comment
P000 Software version (read-only) 0 255 -
P001 Base setpoint for setpoint entry ± 3K 32 8 32 °C
P002 Switching on / off hysteresis valves 1 0 255 °C/10
P003 Neutral zone in a 4-pipe system 3 0 255 °C/10
P004 Cooling without fan support 0 0 255 °C/10
P005 Heating without fan support 3 0 255 °C/10
P006
Hysteresis fan On/Off
(ventilation-only mode) 5 0 255 °C/10
P007 P-band for heating 17 0 100 °C/10
P008 P-band for cooling 20 0 100 °C/10
P009
Offset to the base setpoint for
Setpoint input +/- 3K 0 0 10 °C
P010
Clip-on sensor:
Limit value temperature to activate
fan stages 1 and 2 in heating mode 29 0 255 °C
P011
Clip-on sensor:
Limit value temperature to activate
fan stages 3 and 4 in heating mode
31 0 255 °C
P012
Clip-on sensor:
Limit value temperature to activate
fan stage 5 in Heating mode
33 0 255 °C
P013
Clip-on sensor:
Hysteresis for limit value temperatures
P010, P011, P012, P014
10 0 255 °C/10
P014
Clip-on sensor:
Limit value temperature to activate
fan stages in Cooling mode
18 0 255 °C
P015 Function of input AI1 0 0 19 -
P016 Function of input AI2 0 0 19 -
P017 Function of input AI3 0 0 9 -
P018
Raising the cooling setpoint in
Eco mode 30 0 255 °C/10
P019
Lowering the heating setpoint in
Eco mode 30 0 255 °C/10
P020 Default value must be set 6 0 15 -
P021 Default value must be set 6 0 15 -
P022 Default value must be set 0 0 1 -
P023 Default value must be set 0 -99 127 °C/10
P024 Default value must be set 0 -20 20 01.10.12
P025 Default value must be set 0 -99 127 °C/10
P026 Default value must be set 0 -20 20 01.10.12
P027
Fan setting: Maximum running time of manual
Fan mode 0 0 255 minutes
P028
Rinsing function: Fan stage during rinsing
function 2 1 5 -
P029 Continuous fan operation 1 0 1 -
P030 Default value must be set 12 0 255 °C
P031 Default value must be set 27 0 255 °C
P032 Rinsing function: Maximum idle time of fan 15 0 255 minutes
P033 Rinsing function: Duration of rinsing function 240 0 255 S
