KaControl for Door Air Curtains
INSTALLATION AND OPERATING INSTRUCTIONS
43
Door air curtains 1.96
Function Settings Min Max Unit Comment
P034
Rinsing function: Activation in operating modes
0 = Rinsing function disabled
1 = Rinsing function is enabled in:
- Cooling mode
- Automatic mode
Rinsing function is enabled in:
- Heating mode
- Automatic mode
Rinsing function is enabled in:
- Cooling mode
- H
0 0 3 -
P035 Default value must be set 0 0 255 s
P036
Setpoint setting
0 = Setpoint setting absolute
1 = Setpoint setting +/- 3K 1 0 1 -
P037
Display:
0 = No display
1 = Display of setpoint temperature
2 = Display of room temperature
3 = Display of sensor AI1
4 = Display of sensor AI2
5 = Display of sensor AI3
6 = Display of fan speed in %
0 0 6 -
P038
8 = Eco/Day mode changeover
26 = Eco/Day mode changeover + changeover
Heating/cooling via clip-on sensor
(2-pipe system)
72 = ON/OFF changeover
90 = ON/OFF changeover + Heating / cooling
changeover via clip-on sensor
(2-pipe system)
105 0 255 -
P039
Digital output V2:
0= No function
1= Heating requirement
2= Cooling requirement
3= Collective fault signal
1 0 3 -
P040
Valve actuation by means of pulse width modulation
0 = Function is disabled
1 = Function is enabled
0 0 1 -
P041
Reset time of PI controller to actuate the fan in
automatic fan mode
If P41=0 a PI controller is enabled.
Recommended reset time when using a
PI controller:
Reset time = 13 minutes
0 0 20 minutes
P042 Fan setting: Lock and released fan stages 3 0 127 -
P043 Digital input DI1 1 0 14 -
P044 Digital input DI2 2 0 14 -
