KaControl for Door Air CurtainsINSTALLATION AND OPERATING INSTRUCTIONS
INSTALLATION AND OPERATING INSTRUCTIONS
1.96
44
Door air curtains
Function Settings Min Max Unit Comment
P045 Default value must be set 10 0 100 kOhm
P046 Default value must be set 18 12 34 °C
P047 Default value must be set 24 13 35 °C
P048 Default value must be set 10 0 100 kOhm
P049 Default value must be set 90 0 100 kOhm
P050
Fan setting:
Max. fan speed
100 0 100 %
P051
Fan setting:
Min. fan speed
0 0 90 %
P052
Fan setting:
Restricting the fan speed
0 = Fan speed restriction is enabled in Automatic
fan mode and in Manual fan mode
1 = Fan speed restriction is only enabled in
Automatic fan mode
0 0 1 -
P053
Valve actuation by means of pulse width modulation
Valve switching cycle 15 10 30 minutes
P055
Display Heating/cooling symbols:
in Automatic mode
0 = Heating/cooling symbols disabled
in Automatic mode
1 = Heating/cooling symbols enabled
in Automatic mode
0 0 1 -
P056
Setting DI2:
if DIP4=ON
0 = Contact closed ? Heating
Contact open ? Cooling
1 = Contact closed ? Cooling
Contact open ? Heating
1 0 1 -
P057
Setpoint setting on the value of P01
after switching from Eco/Day or ON/OFF:
0 = Function is disabled
1 = Function is enabled 0 0 1 -
P058 Sensor calibration: Sensor AI1 0 -99 127 °C/10
P061 Sensor calibration: Sensor in the KaController 0 -99 127 °C/10
P062 Sensor calibration: Sensor AI2 0 -99 127 °C/10
P064 Sensor calibration: Sensor AI3 0 -99 127 °C/10
P093 Default value must be set 0 0 3 -
P094 Default value must be set 60 1 255 minutes
P095 Default value must be set 0 0 1 -
P097
Reading DIP switches (read-only):
Display the DIP switch settings as a decimal
number.
The decimal number must be converted to
a binary number.
Example:
Display: 37 (decimal)
Conversion: 100101 (binary)
DIP switch setting:
DIP1 = ON
DIP2 = OFF
DIP
-- 0 63 -
