10. Electrical connection for MULTICAL®, ULTRAFLOW®
and Pulse Transmitter
Connecting MULTICAL® and ULTRAFLOW®
ULTRAFLOW®

MULTICAL®
Blue (GND)/11A

11
Red (supply)/9A

9
Yellow (signal)/10A

10
ULTRAFLOW®

Pulse Transmitter

MULTICAL®
In Out
Blue (GND)/11A

11 11A

11
Red (supply)/9A

9 9A

9
Yellow (signal)/10A

10 10A

10
Connecting via Pulse Transmitter
3,65 VDC supply
1)

Pulse Transmitter
Red (+)

60
Black (-)

61
1) from battery or supply module.
If long signal cables are used, please consider the installation carefully. There must
be at least 25 cm between the signal cable and all other cables due to EMC.
