21Kamstrup A/S • 55122070_A2_GB_07.2017
MULTICAL® 603
9 Set-up via front keys
A number of parameters in MULTICAL® 603 can be configured at the installation site. The
configuration is carried out via SETUP loop, which is available as long as MULTICAL® 603 remains in
transport state*, or until the configuration is ended by activating ”End setup”.
You can navigate from USER loop to SETUP loop by keeping the primary key activated for 5
seconds until the text 1-USER appears on the display. Then use the arrow keys to navigate to
3-SETUP and press the primary key once to open the SETUP loop in MULTICAL® 603. Use the
arrow keys to switch to the parameter that you want to change. You can reach the parameter by
pressing the primary key. Then you can switch to the individual figures by pressing the arrow keys,
e.g. minutes under time (3-004). The parameter is set by pressing the primary key shortly several
times. Leave the menu item by keeping the primary key activated until OK is shown in the display.
After 4 min. without activation of the front keys the meter returns to energy reading in USER loop.**
SETUP loop Index number in
display
1.0 Customer number (N
o
1) 3-001
2.0 Customer number (N
o
2) 3-002
3.0 Date 3-003
4.0 Time** 3-004
5.0 Yearly target date 1 (MM.DD) 3-005
6.0 Monthly target date 1 (DD) 3-006
7.0 Flow sensor position: Inlet or outlet flow (A-code) 3-007
8.0 Energy unit (B code) 3-008
9.0 M-Bus primary address internal (N
o
34) 3-009
10.0 M-Bus primary address module 1 (N
o
34) 3-010
11.0 M-Bus primary address module 2 (N
o
34) 3-011
12.0 Averaging time of min./max. P and Q 3-012
13.0 q
hc
*** 3-013
14.0 t offset 3-014
15.0 Radio “ON” or “OFF” 3-015
16.0 Input A1 (preset register) 3-016
17.0 Input B1 (preset register) 3-017
18.0 Meter number of Input A1 3-018
19.0 Meter number of Input B1 3-019
20.0 TL2 3-020
21.0 TL3 3-021
22.0 TL4 3-022
23.0 t5 3-023
24.0 EndSetup 3-024
* MULTICAL® 603 remains in transport state until a flow of 1 % of q
p
or larger has been registered
for the first time. Then the meter can only be brought back to the SETUP loop by breaking the
installation seal and separating the calculator top and base.
** The clock can, under installation seal, be adjusted by all modules.
*** q
hc
can only be changed on meter type 6. If you attempt to access this menu on the meter
types, the display shows the message “Off”.
