4 Kamstrup A/S • 55122070_A2_GB_07.2017
MULTICAL® 603
1 General information
Please read this guide carefully before installing the energy meter.
In case of incorrect mounting, Kamstrup's guarantee obligations no longer apply.
By connecting to 230 V supply, there is a risk of electric shock.
When working on the flow sensor in the installation, there is a risk of outflow of (hot) water
under pressure.
At a media temperature higher than 60 °C, the flow sensor should be shielded from
unintended contact.
Please note that the following installation conditions must be obeyed:
- Pressure stage Kamstrup ULTRAFLOW®: PN16/PN25/PN40, see marking. The
meter marking does not apply to enclosed
accessories.
- Pressure stage Kamstrup sensor pair, type DS: PN16
- Pressure stage Kamstrup pocket sensors, type PL: PN25
At media temperatures above 90 °C, we recommend flange sensors as well as wall-mounting of
MULTICAL®.
At media temperatures below the ambient temperature, MULTICAL® must be wall-mounted, and
the flow sensor must be a condensation-proof version.
