2120
CONFIGURATION System conguration settings
1. GET DEVICE ADDRESS
2. DATE AND TIME
3. SET LCD CONTRAST
4. SET BRIGHTNESS MODE
5. SET MANUAL BRIGHTNESS
6. SET RADAR MESSAGE
(if applicable)
7. SET RADAR SPEED (if applicable)
8. SET DROP OUT VOLTAGE
9. SET USERNAME AND
PASSWORD
10. WEATHER MESSAGES
(if applicable)
Display the address of the sign
Get the current date and time of the Message Sign
Set the date and time
Modify the contrast level of the LCD screen
Specify LED brightness to be determined by the
PHOTOCELL (automatically) or MANUALLY SET
SET ONLY WHEN BRIGHTNESS MODE IS SET TO MANUAL.
Specify the sign brightness.
Select the message to be activated when the radar speed
threshold is reached or exceeded.
Specify the speed threshold (MPH) above which the
RADAR MESSAGE is to be displayed.
NA
Add/Change the user ID and password to log in.
NA
SCHEDULE Schedule message activations
1. SCHEDULE NUMBER
2. SCHEDULE TIME
3. SCHEDULE DAY/DATE
4. SCHEDULE MESSAGE
5. ACTIVATE SCHEDULE
Specify the desired schedule number to create or edit(1-12)
Specify the activation time of day
Specify the day and/or date of activation
Specify the message (permanent, changeable, or blank) to be
scheduled.
Activates the scheduling feature. This mode of operation will
remain activated until either a new ACTIVATE SCHEDULE is
performed,or a DISPLAY MESSAGE command is selected.
CHECK MESSAGE SIGN STATUS
This menu selection lets you view the system status of current message, sign
temperature, battery, and software version. These cannot be edited from this menu.
1. CURRENT MESSAGE
2. SIGN TEMPERATURE
3. POWER VOLTAGE SUPPLY
4. BRIGHTNESS LEVELS
5. CABINET DOOR STATUS
6. SOFTWARE VERSIONS
7. LOCATION
Displays current message that is active on the MB
NA
NA
Photocell level (ambient lighting level 0-15)
Brightness level (current LED brightness 0-15)
Brightness mode (manual or photocell controlled)
NA
Displays current rmware revisions of the Main and Menu
processor codes.
NA
PERMANENT MESSAGE LIST: TEXT
