19KANE 458s MANUAL
O2/EFF DISPLAY
AUX DISPLAY
Fuel type
AUX (auxiliary) display can be
customised via MENU / SCREEN / AUX
Oxygen (%) left after combustion.
Should be 20.9% ± 0.3% in fresh air
Parameters displayed on lines 1, 2, 3, 4,
5 & 6 can be set by the user
Gross efficiency
AUX parameters until changed by user
Flue temperature
Inlet temperature (oC) – normally set by
flue probe during fresh air purge
NO sensor not fitted
Differential temperature
NO sensor not fitted
TRANSFERING RESULTS
To print, simply press and release the button to send results to our
optional KANE IRP-2 printer or KANE’s App via wireless module – you
can stop printing by pressing again.
Your analyser’s side lights highlight the displays the active line.
Use or to change the pointer.
Press to select a line. The side lights now ash.
Use or to scroll or change the selected line.
Press to exit a line.
