Kane 458s - Analyser Layout

8 KANE 458s MANUAL
ANALYSER LAYOUT
Battery
charger
Watertrap drain with
red plug
Flue probe
temperature T1
Inlet temperature T2
Pressure
connection P1
Pressure
connection P2 –
differential
Flue gas
inlet
On / Off
Function keys
– see below
Water trap &
particle filter
Rotary switch
Red connector
– plugs into Flue
Gas Inlet
Flue Probe Temperature Plug –
into T1
Narrow (+ve) pin must be on
right side
Flue Probe Hose
