Appliance commissioning test follows UK Technical Bulletin 143 (TB143)
tests - It is not a substitute for appliance manufacturer instructions.
Rotate dial to COM TEST then press & ENTER to follow on screen
instructions:
TEST 1 - CHECK APPLIANCE AT MAX GAS RATE
Switch on appliance to max rate & zero analyser in fresh outdoor air.
Once stable at appliance maximum gas flow rate, insert flue probe into flue
air inlet to measure:
For devices that measure CO2 levels - readings must be stable & less than
or equal to 0.20%.
For devices that measure O2 levels - readings must be stable & more than or
equal to 20.6%
TEST 2
Insert flue probe into appliance exhaust outlet to measure CO, CO2 & RATIO
levels - these must be within manufacturer instructions.
If manufacturer instructions are not available CO must be under 350ppm &
RATIO under 0.0040.
TEST 3 - CHECK APPLIANCE AT MINIMUM GAS FLOW
RATE WHERE POSSIBLE
Once appliance is stable at minimum gas rate, measure CO, CO2 & RATIO
levels - these must be within manufacturer instructions.
If manufacturer instructions are not available, CO must be under 350ppm &
RATIO under 0.0040.
To finish press ENTER to continue, then press & ENTER
TEST 4 - MEASURE FLOW & RETURN
TEMPERATURES FROM APPLIANCE
COMMISIONING tests are automatically stored in memory with a log
number.
Send COMMISIONING test log to your optional KANE-IRP3 printer by
pressing ENTER or wirelessly to your KANE LIVE App using & ENTER
28 KANE458s MANUAL
12
12.1
APPLIANCE COMMISSIONING TEST
TESTS
