Operating Instructions KBL 3500
Technical Data
Ambient conditions
Installation site In dry rooms (booths) with suffi cient airing (intake/discharge)
Relative humidity: ≤ 70%
Room temperature: ≤ 30
•
•
Electrical data
Mains voltage 3-phase operation: 3x 220 V / ~ / 60 Hz
2-phase operation: 2x 220 V / ~ / 60 Hz
Wire cross section 3-phase operation: 4x AWG10
2-phase operation: 3x AWG10
Unit data KBL 3500
Super Power Ultra Power Super Power XXL
Lamps 3x 316 W
megaLine HP 500
3x 316 W
megaLine HP 500
—
Filter panes T324 T324 —
Tubes, canopy 16x megaLine
1802 R 100W
18x megaLine
1805 R 140W
16x megaLine
2003 R 120W
Tubes, bed 16x megaLine
1802 R 100W
18x megaLine
2004 R 140W
16x megaLine
2003 R 120W
Fuses Automatic fuse, K-type,
3 pole,
3-phase: 3x 20 A,
2-phase: 2x 30 A,
with ground fault cir-
cuit interrupter
Automatic fuse, K-type,
3 pole,
3-phase: 3x 25 A,
2-phase: 2x 30 A,
with ground fault cir-
cuit interrupter
Automatic fuse, K-type,
3 pole,
3-phase: 3x 20 A,
2-phase: 2x 30 A,
with ground fault cir-
cuit interrupter
Nominal power 4600 W 5700 W 4000 W
Weight ~771.62 lbs (350 kg)
Dimensions (Length x
Width x Height)
When closed: ~89.57“ x ~41.73“ x ~44.69“
(2275 mm x 1060 mm x 1135 mm)
When open: ~89.57“ x ~48.82“ x ~58.66“ (2275 mm x 1240 mm x 1490 mm)
MP3 player
Support for SD cards up to 1 GB
Supported fi le systems on SD card: FAT, FAT32
Supported MP3 fi les: fi xed and variable bit rate,
96-320 kbit/s
•
•
•
