Rev. 1.00
22586_EDEBDA0253-0318-1_EN
30
KBR multicomp F144-3 6DO/6RO
This is displayed after the initialization window if the stage power has already
been programmed. Here, the current total controller state and the currently
measured CosPhi are measured.
Example:
Line 1: currently measured CosPhi 0.71 inductive
Line 2: the controller switches on stages; stages 1 to 4 are already switched to
automatic operation, where:
stages are switched on as compensation power is required.
stages are switched o due to overcompensation.
A
the stage has been switched to automatic mode.
H
the stage has been switched on manually.
0
the stage has been switched o manually.
Press
W to select submenus.
The current readings are displayed in the submenus:
Measuring voltage in volts depending on the selected connection type (Com-
missioning menu, Rot. eld U submenu) in Ph-N (5) or Ph-Ph (ˉ).
Main series transformer apparent current in amps (single-phase value).
Apparent power in kVA, projected as a 3-phase value (provided the network
load is symmetrical).
Active power in kW, projected as a 3-phase value (provided the network load is
symmetrical).
Reactive power in kvar, projected as a 3-phase value (provided the network
load is symmetrical).
Compensation power to achieve the set target cos phi missing.
cos 0.71 IND
 AAAA
8.3 Start menu window:
Description of the display window
