KBR multicomp F144-3 6DO/6RO Description of the display window
Message menu
next 
8.8 Error message window:
Press W to select submenus.
The possible messages and the display conguration are displayed in the sub-
menus of this window.
The following error messages can be congured:
Alarm submenu Possible actions
O Message Alarm relay Message and relay
No measuring voltage
   
No stage power
   
PFC too small
   
THD (voltage harmonics) too high
   
Operating cycle limit exceeded (contactor stages)
   
No measuring current
   
Light load operation
   
Temperature switch-o
   
If a submenu is selected (by pressing W), the error message dialog can be
changed by pressing
U to start entering values, V to change the settings and
X to save them.
