KBR multicomp F144-3 6DO/6RO
11 Technical data
11.1 Measuring and display values
Voltage RMS value of a
measuring interval
Phase - 0 or phase - phase, depending on
conguration
Units [V; kV;] display is switched automatically
Display range 0.00 kV to 99.9 kV
Measuring range 30 - 690 VAC (max. permissible value: 790
VAC)
Current
(apparent current)
RMS value of a
measuring interval
Actual value per phase
Units [A; kA] display is switched automatically
Display range 0.00 A to 999 kA
Measuring range 0.015 - 5 A (max. permissible value: 6 A)
Frequency Network frequency
measurement
f
Network
Units [Hz]
Measuring range 41 - 70 Hz
Apparent power Calculation S
tot
, 3-phase
Units kVA
Display range 0.0 VA to 9999.9 kVA
Active power Calculation P
total
; 3-phase
Units kW
Display range 0.0 W to 9999.9 kW
Reactive power Calculation —> ind.
and cap.
Q
total
; Q
miss
; distinction between ind./cap.
Units kvar
Display range 0.0 var to 9999.9 kvar
Power factor Calculation —> ind.
and cap.
CosPhi; distinction between ind./cap.
CosPhi in display
Display range CosPhi 0.10 ind. <—1 —>0.10 cap.
Temperature Measuring range -10°C to +60°C
Harmonics Distortion factor
(THD) for voltage
Voltage: THD-U
Partial distortion
factors
3
rd
; 5
th
; 7
th
; 9
th
; 11
th
; 13
th
;
voltage harmonic
Units [%]
Measuring period
memory
0.00% to 100%
