KBR multicomp F144-3 6DO/6RO Description of the display window
Service
next 
8.5 Service window:
Press W to select submenus.
The number of connections of each individual capacitor stage is displayed in
the submenus of this window. You can delete the accumulated operating cycles
for all stages by selecting Delete operating cycles. and pressing
U and V
simultaneously.
In addition, the value in the menu item Missing comp. power maximum can
be deleted by pressing
U and V simultaneously, resetting the PFC too small
message. If the set target cos phi is not reached, despite all available stages
being switched on, this message is displayed after the set alarm delay time has
elapsed.
The alarm delay can be set in the Switching performance / Alarm delay menu.
You can also delete the number of overtemperature switch-o s here (this menu
item is only displayed if temperature measurement is activated and accumulat-
ed switch-o s are displayed).
NOTE
The alarm delay can be set in the Switching performance / Alarm delay menu.
