Operation of the Drive
4.2 Parameter Summary
1)
Enter-Parameter
2)
depending on power circuit
Display Parameter Setting range Resolution Factory setting
CP. 0 Password input 0...9999 1 –
CP. 1 Actual frequency display – 0.0125 Hz –
CP. 2 Set frequency display – 0.0125 Hz –
CP. 3 Inverter status display – – –
CP. 4 Phase current – 0.1 A –
CP. 5 Phase current, Peak value – 0.1 A –
CP. 6 Actual inverter load – 1 % –
CP. 7 Actual DC voltage – 1 V –
CP. 8 Actual DC voltage, Peak value – 1 V –
CP. 9 Output voltage – 1 V –
CP.10 Minimum frequency 0…400 Hz 0.0125 Hz 0 Hz
CP.11 Maximum frequency 0…400 Hz 0.0125 Hz 70 Hz
CP.12 Acceleration time 0.01…300.00 s 0.01 s 5.00 s
CP.13 Deceleration time(-1 see CP.12) -1; 0.01…300.00 s 0.01 s 5.00 s
CP.14 S-curve time 0.00 (off)…5.00 s 0.01 s 0.00 s (off)
CP.15 Torque boost 0.0…25.5 % 0.1 % 2.0 %
CP.16 Rated frequency 0…400 Hz 0.0125 Hz 50 Hz
CP.17
1)
Voltage stabilization 1…650 V (off) 1 V 650 (off)
CP.18
1)
Carrier frequency 2/4/8/12/16 kHz – –
2)
CP.19 Fixed frequency 1 -400...400 Hz 0.0125 Hz 5 Hz
CP.20 Fixed frequency 2 -400...400 Hz 0.0125 Hz 50 Hz
CP.21 Fixed frequency 3 -400...400 Hz 0.0125 Hz 70 Hz
CP.22
1)
DC-braking, Mode 0…9 1 7
CP.23 DC-braking, Time 0.00…100.00 s 0.01 s 10.00 s
CP.24 Max. ramp current 0…200 % 1 % 140 %
CP.25 Max. constant current 0…200 % (off) 1 % 200 % (off)
CP.26
1)
Speed search condition 0…15 1 8
CP.27 Quick stop time 0.00…300.00 s 0.01 s 2.00 s
CP.28 Response of ext. overtemperature 0…7 1 7
CP.29
1)
Analog output 1 0…12...20 {F5G} 1 2
CP.30 Analog output 1, Amplification -20.00…20.00 0.01 1.00
CP.31
1)
Relay output 1 0…58...66 {F5B} 1 4
CP.32
1)
Relay output 2 0…58...66 {F5B} 1 27
CP.33 Relay output 2, Switching level ±30000.00 0.01 4.00
CP.34
1)
Source of rotation direction 0…9 1 2
CP.35
1)
AN1 interface selection 0…2 1 0
CP.36 AN1 zero point hysteresis -10.0…10.0 % 0.1 % 0.2 %
